Description
Chain bucket (trough) conveyor is a conveying equipment for continuous conveying of bulk materials. It is suitable for conveying dry granular materials with particle size of about 50 mm (the maximum particle size is not more than 150 mm) with horizontal or inclined angle ≤ 60 ° and especially suitable for conveying some solid materials with high temperature, large capacity, large bulk, sharp edges and strong grindability. Chain bucket conveyor products are widely used in power plants, mines, coal and other industries for the transportation of various loose materials, such as boiler ash, cement clinker, slag, coke, gravel, etc., especially some materials with high temperature, large capacity, large size, sharp angle and strong grinding.
Advantages of chain bucket conveyor
1. The traction chain of the conveyor adopts high-strength double row heavy plate chain, which runs stably and reliably and has long service life.
2. The spring spiral tension device is used in the tail part of the machine, which can automatically adjust the tension of the traction chain. It is especially suitable for long-distance and heavy-duty conveyors;
3. The process layout is flexible; it can be set up high, on the ground or in the pit, installed horizontally or obliquely, or installed horizontally and obliquely;
4. Back drive mechanism, compact structure, easy to install.
Technical parameters
|
Model |
Hopper width Mm |
Chain Speed Range |
Conveying Capacity M³/H |
||
|
β≤20° |
20°<β≤40° |
40°<β≤60° |
|||
|
LD-350xL |
350 |
3.5~17.5 |
14~70 |
7~35 |
5~25 |
|
LD-450xL |
450 |
3.5~17.5 |
18~90 |
9~45 |
6~30 |
|
LD-630xL |
630 |
3.5~17.5 |
24~120 |
12~60 |
9~45 |
|
LD-800xL |
800 |
3.5~17.5 |
32~160 |
16~80 |
11~55 |
|
LD-1000xL |
1000 |
3.5~17.5 |
40~200 |
20~100 |
14~70 |
|
DLD-350xL |
350 |
3.5~17.5 |
12~60 |
6~30 |
4~20 |
|
DLD-450xL |
450 |
3.5~17.5 |
14~70 |
7~35 |
5~25 |
